Description
High-Acoustic Multi-Variant Digital Transceiver Platform
Scalable Enterprise Fleet Communications Across VHF and UHF Bands
The Icom F1100D and F2100D Series represents a highly versatile generation of commercial handheld business radios engineered to adapt smoothly to diverse operational roles within a single workforce. This comprehensive product line spans across both VHF frequencies (F1100D models) and UHF frequencies (F2100D models) to ensure clear, high-penetration signal propagation whether your team operates across open industrial yards or inside high-density concrete facilities. By consolidating your fleet onto a unified hardware architecture, deployment becomes streamlined while maintaining specific user interfaces tailored to individual worker responsibilities.
To satisfy different tier workflows, this platform divides its physical designs into three distinct hardware configurations: a streamlined no-display version for plug-and-play simplicity, a balanced middle-tier layout featuring a display with directional keys, and a heavy-duty multi-button model with a full numeric pad for complex data routing.
Every unit in this consolidated series shares an industry-leading 1500 mW acoustic internal speaker system that works alongside a specially contoured chassis frame to amplify vocal frequencies over extreme ambient warehouse or construction noise. Built to withstand severe environmental stress, the entire family features ruggedized IP67 waterproof enclosures alongside strict military-grade structural resilience certifications. Whether managing local retail operations or directing multi-site industrial plants, this agile system delivers maximum operational uptime.
Model Variants
| Model |
Frequency Band |
Interface Style |
Display |
Controls |
Channel Capacity |
| F1100D |
VHF (136–174 MHz) |
No Display |
None |
No Keypad |
16 Channels |
| F1100DS |
VHF (136–174 MHz) |
Display with Basic Keys |
8-Character LCD |
4 Function Keys |
128 Channels / 8 Zones |
| F1100DT |
VHF (136–174 MHz) |
Display with Full Keypad |
8-Character LCD |
Full Alphanumeric Pad |
128 Channels / 8 Zones |
| F2100D (Low) |
UHF Low (400–470 MHz) |
No Display |
None |
No Keypad |
16 Channels |
| F2100D (High) |
UHF High (450–512 MHz) |
No Display |
None |
No Keypad |
16 Channels |
| F2100DS (Low) |
UHF Low (400–470 MHz) |
Display with Basic Keys |
8-Character LCD |
4 Function Keys |
128 Channels / 8 Zones |
| F2100DS (High) |
UHF High (450–512 MHz) |
Display with Basic Keys |
8-Character LCD |
4 Function Keys |
128 Channels / 8 Zones |
| F2100DT (Low) |
UHF Low (400–470 MHz) |
Display with Full Keypad |
8-Character LCD |
Full Alphanumeric Pad |
128 Channels / 8 Zones |
| F2100DT (High) |
UHF High (450–512 MHz) |
Display with Full Keypad |
8-Character LCD |
Full Alphanumeric Pad |
128 Channels / 8 Zones |
Key Features & Benefits
-
Acoustically Amplified 1500 mW Audio: High-capacity speaker cones push clear voice paths over ambient mechanical roars or howling outdoor winds.
-
Dual-Split UHF Availability: Offers targeted hardware built specifically to match localized low-UHF systems or high-tier public service frequencies.
-
IP67 Waterproof Protection: Complete IP67 structural shielding keeps internal electronics running after water submersions up to one meter deep for thirty minutes.
-
AquaQuake Water Clearing: Drives a fast low-frequency acoustic buzzing sequence to instantly push trapped water beads away from the speaker fabric.
-
Digital Over-the-Air Alias Display: Instantly projects incoming user names directly onto LCD-equipped models without complex background programming.
-
Automated Worker Protection Monitors: Integrated physical movement tracking logs severe impacts or stagnation to execute automated emergency voice alerts.
Specifications
| Attribute |
Details |
| Brand |
Icom |
| Voltage Input |
7.5V DC Nominal |
| Operating Temperature |
-30°C to +60°C |
| Audio Output |
1500 mW |
| Transmit Power |
5W (VHF & Low-UHF) / 4W (High-UHF) |
| Military Standard |
MIL-STD-810G |
| Voice Codec |
AMBE+2 |
What's Included
| Description |
SKU |
Status |
| Digital Handheld Transceiver |
Selected Variant |
Included |
| 2400 mAh Li-Ion Battery |
BP280 |
Included |
| Desktop Charging Cradle |
BC213 |
Included |
| Wall Power Supply Adapter |
BC123SA or BC242 |
Included |
| Spring Belt Clip |
MB133 |
Included |
| Band Antenna |
Factory Selected |
Included |
Recommended Accessories
More Resources
Frequently Asked Questions
Does the Icom F1100D or F2100D need to be programmed?
Yes, these radios must be programmed with your licensed frequencies before use. You'll be asked at checkout whether you'd like programming, or you can add it in advance via our Atlantic Radio Programming Services page. To program them yourself, you'll need the Icom CS programming software and the OPC-478UC USB programming cable, both sold separately.
What is the purpose of the Over-the-Air Alias feature?
On display-equipped variants (DS and DT models), this function captures identification codes embedded inside digital transmissions and instantly decodes the signal to print the caller's actual name on your screen, completely removing the need to manually program comprehensive user lists into every radio.
How long will the standard battery pack operate in the field?
When paired with the standard BP-280 battery pack, the VHF variants deliver up to 18 hours of typical operation. The UHF models provide approximately 17 to 18 hours of field runtime depending on your configuration, easily sustaining multi-shift work cycles.
Can I program both digital and analog channels into the same radio?
Yes, the series fully supports analog/digital mixed-mode operation. The internal digital processor scans across conventional analog frequencies and modern digital channels concurrently, automatically replying to whichever protocol initiated the call.
What does the Surveillance setting do for security staff?
When activated, the radio temporarily blocks all audible notification beeps and turns off the active status LED indicator lights, letting personnel receive incoming dispatches completely silently without giving away their location.
Are special tools needed to clear water from the speaker grill?
No extra tools are required. Activating the integrated AquaQuake feature forces the radio to emit a low-pitched buzzing tone through the speaker module. The structural vibration mechanically breaks surface tension, expelling trapped water from the mesh instantly.
Warranty
The Icom F1100D and F2100D series includes a 2-year manufacturer's warranty on the radio and a 1-year warranty on included accessories. Please contact Atlantic Radio Communications for warranty claims, support, or replacement inquiries.
