Description
Rugged Broadband Push-to-Talk Portable Radio
High-performance WAVE PTX cellular radio featuring multi-carrier 4G LTE switching, dual-band Wi-Fi calling, IP67 antimicrobial casing, 18-hour battery life, and automated safety features.
The Motorola TLK 200 is a commercial-grade broadband Push-to-Talk (PTT) portable radio built for demanding, multi-shift workforce environments. Powered by Motorola’s WAVE PTX push-to-talk service, the device integrates an advanced MVNO SIM card with multi-carrier LTE redundancy. Upon power-up, the TLK 200 automatically connects to the strongest available Tier-1 cellular network and intelligently re-scans and connects within approximately 10 seconds if a signal is lost, eliminating carrier dead zones. Combined with optional SafeGuard subscription packages offering unthrottled, full-speed roaming across the U.S., Canada, and Mexico alongside dual-band 2.4 GHz and 5.0 GHz Wi-Fi calling, the TLK 200 delivers boundary-free operational connectivity.
Engineered for frontline durability and hygiene, the Motorola TLK 200 features an IP67 dustproof and water-submersible enclosure with a shareable antimicrobial housing built to MIL-STD-810 standards. Upgraded processing and advanced background noise suppression deliver loud, clear voice output through a high-performance 3W speaker, reducing misheard instructions in high-noise environments. A high-capacity 2500 mAh Li-Ion battery (PMNN4578) delivers up to 18 hours of continuous operation (5:5:90 duty cycle), ensuring non-stop uptime across consecutive rotations. Complete with a 2.5-line display, 2.5mm locking audio jack, USB-C charging port, direct open Bluetooth 5.0 pairing, and automated worker protection (Fall Alert, Lone Worker, and Emergency Calling), the TLK 200 seamlessly unites broadband PTT units, MOTOTRBO radios, and smart devices under FCC Licensing standards.
Key Features & Benefits
-
Multi-Carrier Auto-Switching: Built-in MVNO SIM automatically selects the strongest Tier-1 LTE network and auto-switches in 10 seconds if connection drops.
-
North American SafeGuard Roaming: Delivers unthrottled, full-speed PTT roaming across the U.S., Canada, and Mexico without daily data caps.
-
Dual-Band Wi-Fi Connectivity: Operates over 2.4 GHz and 5.0 GHz enterprise Wi-Fi networks (802.11 a/b/g/n/ac) for indoor coverage.
-
IP67 Submersible & Antimicrobial Casing: Completely dustproof and water-submersible housing rated to MIL-STD-810 with antimicrobial surface protection.
-
18-Hour Shift Battery Capacity: 2500 mAh rechargeable Li-Ion battery pack (PMNN4578) provides 18 hours of operation for back-to-back shifts.
-
Automated Worker Protection: SafeGuard subscription enables automated Fall Alert man-down detection, Lone Worker timers, and Emergency Calling/Alerting.
-
Hassle-Free Bluetooth 5.0 Pairing: Open Bluetooth 5.0 architecture enables direct user pairing with wireless earpieces without portal setup.
-
Cross-Platform Interoperability: Bridges voice calls between TLK devices, MOTOTRBO radios (R7, XPR series), and WAVE PTX mobile apps.
Specifications
| Attribute |
Details |
| Brand |
Motorola Solutions |
| Model / SKU |
TLK 200 / WAVE PTX Series |
| Product Type |
Broadband PTT / LTE & Wi-Fi Portable Radio |
| Cellular Network Compatibility |
4G LTE-FDD (Bands B2, B4, B5, B7, B12, B13, B17, B66) |
| Wi-Fi Connectivity |
Dual-Band 2.4 GHz & 5.0 GHz (802.11 a/b/g/n/ac) |
| Bluetooth Profile |
Bluetooth 5.0 (BLE, SPP, HSP) |
| Ingress Protection / Durability |
IP67 Dustproof & Water Submersible / MIL-STD-810 |
| Housing Finish |
Antimicrobial Surface Treatment |
| Battery Chemistry / Capacity |
Li-Ion 2500 mAh (PMNN4578) |
| Battery Operating Hours |
(5:5:90) Up to 18 Hours |
| Charging Interface |
USB Type-C & Bottom Charging Contacts |
| Accessory Audio Connector |
2.5mm Audio Jack with Mechanical Lock |
| Dimensions (H x W x D) |
139 x 55 x 24 mm (5.47 x 2.17 x 0.94 in) without antenna |
| Weight (with battery) |
192.6 g (6.79 oz) |
Compatibility
Compatible WAVE PTX Radios, Accessories & MOTOTRBO Systems
What’s Included
Recommended Accessories
Audio Accessories & Earpieces
Charging & Power Hardware
More Resources
Frequently Asked Questions
How does multi-carrier network auto-switching work on the TLK 200?
The Motorola TLK 200 features an MVNO SIM card that automatically selects the strongest Tier-1 LTE network upon startup. If cellular signal is lost, the radio automatically scans and connects to the next strongest available network in roughly 10 seconds.
Does the TLK 200 support Wi-Fi calling?
Yes. The TLK 200 supports Wi-Fi calling over both 2.4 GHz and 5.0 GHz commercial and enterprise Wi-Fi networks (802.11 a/b/g/n/ac).
Can the TLK 200 talk directly to MOTOTRBO two-way radios?
Yes. Through WAVE PTX service integration, the TLK 200 seamlessly bridges voice communication between LTE handhelds, MOTOTRBO land mobile radios (such as R7 and XPR series), and smartphones running the WAVE PTX mobile app.
What worker safety features are enabled with the SafeGuard package?
With a SafeGuard subscription, the radio activates automated Fall Alert man-down detection, Lone Worker response timers, and dedicated Emergency Calling/Alerting.
What is the water resistance rating of the Motorola TLK 200?
The TLK 200 holds an IP67 rating, making it completely dustproof and water-submersible. It also features a durable antimicrobial outer casing.
Warranty
Comprehensive 3-year manufacturer’s hardware replacement and software update warranty.
