Description
1500mAh Li-Ion Replacement Battery for Hytera BD5 and BD6 Radios
The Hytera BL1506 is a 1500mAh, 7.2V lithium-ion battery for compatible Hytera BD5 and BD6 portable radios, including BD502i, BD552i and BD612i. Use it to replace an aging pack or keep a charged spare ready for the next shift.
For a busy retail floor, school or hospitality team, a spare battery can help reduce time spent waiting at the charger. The BL1506 weighs approximately 73g and carries an IP54 rating. Its actual operating time depends on the radio, frequency band, transmit activity, battery condition and working environment.
Key Features
-
1500mAh capacity: Standard-capacity rechargeable Li-ion pack for the compatible models listed below.
-
7.2V nominal voltage: Match the BL1506 part number and radio application when selecting a replacement.
-
Up to 16 hours of digital operation: Manufacturer reference under a 5/5/90 duty cycle, not continuous transmission or a guaranteed shift length.
-
IP54 protection: Dust and splashing-water resistance under the applicable test conditions, not an immersion rating.
-
Compact spare: Approximately 73g, with manufacturer-listed dimensions of 84.65 × 51.98 × 13.3mm.
Specifications
| Attribute |
Details |
| Manufacturer / model |
Hytera BL1506 |
| Product type |
Rechargeable portable-radio battery pack |
| Chemistry |
Lithium-ion (Li-ion) |
| Nominal capacity |
1500mAh |
| Nominal voltage |
7.2V |
| Dimensions, H × W × D |
84.65 × 51.98 × 13.3mm |
| Battery weight |
Approximately 73g; battery only, not packed shipping weight |
| Ingress protection |
IP54 |
| Discharge operating temperature |
−20°C to +60°C; not the charging-temperature range |
| One-month storage temperature |
−20°C to +60°C; not a universal long-term storage recommendation |
| Listed cycle-life reference |
500 cycles; actual usable life depends on charging, storage, temperature and use |
| Digital runtime reference |
Up to 16 hours under a 5/5/90 duty cycle; varies with radio and frequency |
Compatible Radios
| Radio models |
Application |
| Hytera BD502i |
BL1506 replacement or spare battery |
| Hytera BD552i |
BL1506 replacement or spare battery |
| Hytera BD612i |
BL1506 replacement or spare battery |
| BD502, BD505, BD552, BD555 |
Additional regional model references retained from this listing. Match the radio's exact model and specified battery before ordering. |
The BL1506 is not a universal Hytera battery. Select by the specified part number and radio model rather than capacity or connector appearance alone. A battery's IP54 rating does not establish a different rating for the assembled radio or suitability for hazardous locations.
What's Included
| Item |
Reference / details |
Status |
| Rechargeable battery pack |
Hytera BL1506, 1500mAh Li-ion |
Included |
| Portable radio |
Compatible Hytera handset |
Sold separately |
| Charger and power supply |
Approved charging equipment for the battery |
Sold separately |
Battery Life: What 16 Hours Means
Hytera's BL1506 reference uses a 5/5/90 duty cycle: 5% transmitting, 5% receiving and 90% standby. It is not 16 hours of continuous talking. As a specific example, the BD612i specifications list approximately 16 hours digital or 12 hours analog with the 1500mAh battery under that profile.
Frequent transmission, high output settings, temperature and battery aging can shorten runtime. For longer shifts, plan charging and spare-battery rotation around your team's actual radio use rather than treating the published figure as a guarantee.
Charging, Care and Storage
- Use the charger specified for the BL1506 and its correct power supply. Similar-looking charger pockets do not establish compatibility.
- Power the radio off during charging as recommended in the BD502i user guide. Seat the battery correctly and follow the charger indicators and instructions.
- Keep the pack and charging contacts clean and dry. Do not charge a wet, swollen, cracked or otherwise damaged battery.
- The −20°C to +60°C specification is for discharge, not permission to charge at those extremes. Follow the approved charger and battery instructions for charging temperatures.
- Store spare packs away from excessive heat and metal objects that could bridge the contacts. Follow manufacturer storage instructions for the planned duration.
Recommended Charging Equipment
Hytera CH10L23 Desktop Charger: Single-unit charger listing that identifies the BL1506 battery. The power supply is a separate selection.
Hytera PS1014 Power Supply: US-plug supply listed for the CH10L23. It powers the charger, not the battery directly.
Hytera MCL19 Six-Unit Charger: Multi-unit charging option for compatible BD502i, BD552i and BD612i fleet equipment. Select the required kit and power arrangement.
Frequently Asked Questions
Which radios use the BL1506?
The main supported models in this listing are BD502i, BD552i and BD612i. BD502, BD505, BD552 and BD555 are retained as regional references; match the exact model's specified battery before purchase.
Is this a 1500mAh or 2000mAh battery?
The BL1506 is a 1500mAh battery. Higher-capacity packs are separate products and must be selected for the exact radio and charger application.
What is the BL1506 voltage?
Hytera lists a nominal voltage of 7.2V for the BL1506.
Will it give me 16 hours of continuous use?
The up-to-16-hour digital reference uses a 5/5/90 transmit/receive/standby duty cycle. Continuous or frequent transmission uses more energy and produces shorter operating time.
Does analog mode have the same runtime?
Not necessarily. For example, the BD612i lists 16 hours digital and 12 hours analog with the 1500mAh battery at 5/5/90. Results depend on the model and use.
Is the BL1506 waterproof?
It is IP54-rated for dust and splashing-water resistance, not submersion. Keep charging contacts dry and follow the radio and charger instructions.
Does it include a charger?
No. This listing is for the BL1506 battery. A compatible charger and its required power supply are sold separately.
Can I charge it at −20°C?
The listed −20°C minimum is a discharge specification, not a charging specification. Use the charging-temperature limits in the battery and approved charger instructions.
Does 500 cycles guarantee a fixed lifespan?
No. The manufacturer lists a 500-cycle reference. Capacity retention and useful life vary with handling, storage, temperature and charge/discharge conditions.
Do I need programming after replacing the battery?
This is a power accessory, not a programming cable, software license or radio configuration service. Select the correct battery for your handset and follow its installation instructions.
Warranty
1-year manufacturer's warranty. Applicable manufacturer terms and exclusions apply.
